Safety Precautions
Safety Precautions
To prevent injury to the user or other people and property damage, the following instructions must be
followed.
Incorrect operation due to ignoring of instruction will cause harm or damage, the seriousness is classified
by the following indications.
WARNING
CAUTION
:
:
This symbol shows the possibility of causing death or serious injury.
This symbol indicates the possibility of injury or damage to
properties only.
The items to be followed are classified by the following symbols.
Never Do This
Always Do This
WARNING
Plug in the power plug
properly.
Do not operate or stop the
unit by inserting or pulling
out the power plug.
Do not damage or use an
unspecified power cord.
Otherwise, it will cause electric
shock or fire due to heat
generation or electrical shock.
It will cause electrical shock or
fire due to heat generation.
It will cause electrical shock or fire.
If the supply cord is damaged, it
must be replaced by a special cord
or assembly available from the
manufacturer or its service agent.
Do not modify power cord
length or share the outlet
with other appliances.
Do not operate with wet
hands or in damp
environment.
Do not direct airflow at room
occupants only.
It will cause electrical shock or
fire due to heat generation.
It may cause electrical shock.
This could damage your health.
-3-
The airconditioner should be installed in accordance with national wiring regulation
Following circuit breaker/fuse rating to be used as per unit specification
LW-C12..CI(12000 Btu/Hr) 15A, LW-N18..CI(18000 BTu/Hr )-20A ,LW-N24..CI(24,000 Btu/Hr )-30A
If your airconditioner is not provided with a plug then there should be some means for
disconnection of both live & neutral poles having a contact seperation of minimum 3mm & must be
Incorporated in fixed wiring in accordance to wiring rules
