Hyundai Basiq ELLE HV19 [5/40] Technical specifications

Electric convector

Technical specications

H-HV16-10-UI620 H-HV16-15-UI621 H-HV16-20-UI622

Rated power

consumption

W 1000 1500 2000

Power supply V/Hz 220~/50 220~/50 220~/50

Rated current А 4,5 6,8 9,1

Protection class

IP20 IP20 IP20

Electrical protection

class

Class I Class I Class I

Heating area m² 10–13 15–18 20–22

Net weight kg 3 3,8 4,7

Device dimensions mm 400х460х80 400х595х80 400х920х80

H-HV15-10-UI617 H-HV15-15-UI618 H-HV15-20-UI619

Rated power

consumption

W 1000 1500 2000

Power supply V/Hz 220~/50 220~/50 220~/50

Rated current А 4,5 6,8 9,1

Protection class IP20 IP20 IP20

Electrical protection

class

Class I Class I Class I

Heating area m² 10–13 15–18 20–22

Net weight kg 2,8 3,4 4,1

Device dimensions mm 400х460х80 400х595х80 400х920х80

H-HV19-10-UI623 H-HV19-15-UI624 H-HV19-20-UI625

Rated power

consumption

W 1000 1500 2000

Power supply V/Hz 220~/50 220~/50 220~/50

Rated current А 4,5 6,8 9,1

Protection class IP24 IP24 IP24

Electrical protection

class

Class I Class I Class I

Heating area m² 10–13 15–18 20–22

Net weight kg 3,2 4 5,5

Device dimensions mm 400х460х80 400х595х80 400х920х80
