Stitch Types: Chain Stitch
- Right (C-1), Center (C-2), Left (C-3)
Cover Stitch
- Narrow Left
- Narrow Right
- Wide
- Triple
Overlock Stitch
-
4-Thread Overlock (narrow and wide)
- 3-Thread Overlock (narrow and wide)
- 3-Thread Flatlock
-
3-Thread Rolled Hem
3-Thread Wave
3-Thread Rolled Wave
-
2-Thread Overlock (narrow and wide)
- 2-Thread Flatlock (narrow and wide)
Combined Stitch
- 5-Thread Safety Stitch
- 6-Thread Stitch
- 7-Thread Stitch
- 8-Thread Stitch
Stitch Width: Cover Stitch
- Triple Cover Stitch : 6.0mm
- Cover Stitch - Wide : 6.0mm
- Cover Stitch - Narrow: 3.0mm
Overlock Stitch
- Standard 2/3/4-Thread Overlock with left needle : 5.5-7.5mm
- Standard 2/3/4-Thread Overlock with right needle : 3.0-5.0mm
- 3-Thread Rolled Hem with right needle : 1.5mm
Combined Stitch
- 5-Thread Safety Stitch: 5.5-16.0mm
- 6-Thread Ultra Stitch: 8.5-16.0mm
- 7-Thread Ultra Stitch: 10.5-16.0mm
- 8-Thread Ultra Stitch:13.5-16.0mm
Stitch Length: 1.0-4.0mm
Differential Feed: Gathering effect: N ~ 2
Stretching effect: N ~ 0.6
Presser Foot: Snap on exclusive feet for evolve
Handwheel: Rotate forward (counter clockwise)
Loopers: 3 Loopers: Upper(U), Lower(L), Chain(C)
Needle System: Schmetz or Organ ELx705CF #80/12 - #90/14
Number of Needles: 5 total: 3 Chain/Cover Stitch, 2 Overlock
Sewing Speed: Up to 1500 s.p.m.
Machine Weight: 8.3 kg/18 lbs.
Light Bulb: 15W / 110V or 15W / 240V
