BABYLOCK BLES8 Ovation [9/92] Needles
![BABYLOCK BLES8 Ovation [9/92] Needles](/views2/2005138/page9/bg9.png)
Your Baby Lock evolve serger is set up to use either Schmetz or Organ ELx705CF needles size 90/14. This
is suitable for most medium and heavyweight fabrics. For lightweight fabrics use size 80/12, ELx705CF nee
-
dles. The ELx705CF needle is a semi-ballpoint design and is suitable for knits and wovens.
O
V
E
R
V
I
E
W
7
Needles
Thread
All types of thread may be used on your Baby Lock, but 100% long-staple polyester thread, crosswound on a
cone, consistently provides the best stitch performance. Because the threads must pass through several thread
guides at high speeds, they must be of uniform thickness and high strength with a minimum amount of linting.
Good-quality cotton or cotton-covered polyester threads sew well, though they produce more lint, creating the
need to clean the machine more frequently. They work well for overedging and seaming, but they may be too
weak or too fuzzy for the rolled edge. Poor grades of thread can result in frequent fraying, breaking and unbal-
anced stitches.
Threads of other fiber contents and weights may be used, depending on their strength and thickness. Testing
will help you determine how easily they can pass through the thread guides, thread slots, needles and loopers.
Important Note: For maximum performance of the Baby Lock evolve, it is recommended to use "100%
polyester-long fiber thread". Recommended brands are Maxi-Lock and Metrosene. This thread also performs
best when used with many decorative threads for sewing specialty decorative techniques.
Optional Accessories
OVERLOCK OPTIONAL ACCESSORIES
Beading Foot B5002-04A-C-E (BLE8-BF)
Blindhem Foot B5002S06A-E (BLE8-BLHF)
Elastic Applicator Foot B5002S09A-E (BLE8-EF)
Lace Applicator Foot B5002S08A-E (BLE8-LF)
Piping Foot/5mm Cording B5002-05A-C-E (BLE8-CF)
Ruffling Foot B5002S07A-E (BLE8-RF)
CHAIN/COVER STITCH OPTIONAL ACCESSORIES
Belt Loop Folder 3/4" B0421S12A-E (BLE8-S12)
Belt Loop Folder 1-1/2" B0421S11A-E (BLE8-S11)
Double Fold Bias Binder 28mm B0421S03A-E (BLE8-S3)
Double Fold Bias Binder 36mm B0421S02A-E (BLE8-S2)
Fabric Guide B0420S01A-E (BLE8-FG)
Pintuck Foot w/2 Guides B5002-06A-C-E (BLE8-PTF)
Plain Hemmer 1/4" B0421S07A-E
(BLE8-S7)
Plain Hemmer 1/2"
B0421S06A-E (BLE8-S6)
Single Downturn Feller 1/4" B0421S10A-E (BLE8-S10)
Single Downturn Feller 5/8" B0421S08A-E (BLE8-S8)
Single Downturn Feller 1" B0421S09A-E (BLE8-S9)
Single Fold Bias Binder 28mm B0421S04A-E (BLE8-S4)
Single Fold Bias Binder 40mm B0421S05A-E (BLE8-S5)
OTHER OPTIONAL ACCESSORIES
Bulb Remover tool
B7525-01A (262011)
Top Stich Needle Size 90 (T-90B)
