![Falmec Line PRO [16/84] Instructions booklet](/views2/2005400/page16/bg10.png)
14
GB
INSTRUCTIONS BOOKLET
WARNINGS
A
This instruction booklet must be kept together with the appliance for future reference. If the appliance is sold or consigned to other
parties, check that the booklet is supplied with it, to ensure that the new user has the correct information on the operation of the range
hood and is aware of the warnings. These warnings have been provided for the your safety and the safety of others. As a result, please
read them carefully before installing and operating the appliance.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person respon-
sible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
The appliance must be installed by qualified personnel, in accordance with the standards in force. If the supply cord is damaged, it must
be re-placed by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. Any modifications that may
be required to the electrical system for the installation of the range hood must only be made by qualified electricians. It is dangerous to
modify or attempt to modify the characteristics of this system. In the event of malfunctions or if repairs are required to the appliance, do
not attempt to solve the problems directly.
Repairs performed by unqualified persons may cause damage. For all repair and other work on the appliance, contact an authorised
service/spare parts centre.
Always check that all the electrical parts (lights, exhaust device), are off when the appliance is not being used. Read the entire instruction
booklet before performing any operations on the range hood.
The range hood must only be used for the exhaust of cooking fumes in home kitchens. The manufacturer disclaims all liability for any
other use of the appliance.
The maximum weight of any object placed above the hood, or hung to it (if possible) must not exceed 1,5 kilos. After installing the
stainless steel hood, clean it in order to remove any residue of the protective glue, and stains of grease or oil. The manufacturer
recommends its cleaning cloth available for purchase. The manufacturer accepts no liability in case of damage caused by the use of
different detergent types.
CAUTION:
This product must be disposed of at end of life according to the rules in force.
SAFETY WARNINGS
The electrical system features an earth connection in compliance with international safety standards; furthermore, it is compliant with
the European standard for electromagnetic compatibility.
Do not connect the appliance to flues (from boilers, fireplaces, etc.). Make sure the mains voltage corresponds to the values on the rating
plate located inside the range hood.
Never cook on “open” flames under the range hood.
Check deep-fryers during use: superheated oil may be flammable.
- Ensure there is adequate ventilation of the room when the rangehood is used at the same time as appliances burning gas or other fuels.
- Do not flambe under the rangehood
- The exhaust air must not be discharged into a flue which is used for exhausting fumes from appliances burning gas or other fuels.
- Ensure that all regulations concerning the discharge of exhaust air have been fulfilled before you use the appliance.
Before performing any cleaning or maintenance operations, disconnect the appliance by unplugging it or using the main switch. The
manufacturer disclaims all liability for any damage that may be directly or indirectly caused to people, things and animals due to the
failure to follow all the instructions provided in this booklet and above all the warnings relating to the installation, operation and
maintenance of the appliance.
- there is a fire risk if cleaning is not carried out in accordance with the instructions.
CAUTION: Accessible parts may become hot when used with cooking appliances.
- Max. length screw for fixing the chimney is 10 mm (provided by the manufacturer).
WARNING: Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards.
Warning only for Australia: hood width less than 90 cm: use max. 4 hobs
TECHNICAL SPECIFICATIONS
B
The technical data pertaining to the electric appliance The technical specifications of the appliance are shown on the rating plates
located inside the range hood.
INSTALLATION
C
(Section reserved for qualified installers of the range hood)
The distance between the hob and the lowest part of the rangehood is normally at least 65 cm (see figure C1). This distance is measuresd
in the lowest part of the rangehood not operating at safety voltage. Based on this detail provided by European Standards, the distance
may be reduced in some models as specified in the general catalogue. If the instructions for installation for the gas hob specify a greater
distance, this has to be taken into account.
In the outside exhaust version, the diameter of the fume discharge duct must be no smaller than the range hood connection.
In the horizontal sections, the duct must slope slightly (around 10%) upwards, so as to better convey the air outside of the room.
Avoid using angled pipes, make sure that the pipes are at least of the minimum length.
Comply with the current regulations on air discharge into the atmosphere.
