De Dietrich DHD770X [11/15] Electrial hook up of the hood

-REMOVAL OF THE FILTER CARTRIDGE (Fig. 3A)

-MOUNTING THE CARBON FILTER (Fig. 13Z)

1.Removethecartridges.

2.Positionthecarbonlteronthecartridgeinsidethehood.

3.Repeattheoperationforallofthecartridges.

- ELECTRIAL HOOK UP OF THE HOOD

This appliance is tted with an H05 VVF 3 conductor, 0.75 mm2 (neutral, phase, and

ground) power cable. This can be hooked up to a 220 – 240 V mono-phase electrical

network by way of a CEI 60083 regulation power socket that must remain accessible after

installation, in conformity to installation regulations.

We decline all responsibility in case of accident caused by a lack of ground connection

or incorrect ground connection. The fuse used must be 10 or 16 A. If the power cable is

damaged, call the after-sales service to avoid any risk.

Attention

Ifthehoodpresentssomeformofanomaly,unplugtheapplianceorremovethefusecorre

spondingtotheappliance’spowerline.
