EN-6

For a voice transmission, press and hold the Call/PTT (transmit) (9)

button and speak into the microphone (8). Hold down this button until

the transmission of your message is complete.

Hold the microphone a minimum of 5 cm from your face.

Note:

- The other device must be set to the same channel and have set the

same CTCSS code (see point 7)

- After completing the transmission and releasing the Call/PTT (9)

button, the other device will make a sound signal (BEEP) to indicate

that this device is ready to transmit.

5. Changing Channels

Press the MENU button (6) once - the number of the current channel

will start ﬂ ashing.

Press the - ▼ button (4) or the- ▲ (5) to change the channel.

Press the Call/PTT -button to (9) conﬁ rm and return to stand-by Mode.

Note:

If no button is pressed within 9 seconds during setting, the unit will

return to standby.

6. CTCSS(Continious Tone Coded Squelch System)

License free radio’s operating on the 446 MHZ frequency band

have 8 available radio channels. If there are many radio’s users in

your neighbourhood, there is a chance that some of these users are

operating on the same radio channel.

To prevent that you receive signals from other users, sub-channels

have been integrated.

Two radio’s will only be able to communicate with each other when

they are operating on the same radio channel and when they have

selected exactly the same sub-channel.

When using CTCSS, a low frequency tone (between 67 and

250 Hz) will be transmitted along with the voice signal. There are

38 available tones to choose from. You are free to choose one of

these 38 available tones. Due to ﬁ ltering, these tones will generally

not be audible so they will not disturb the communication.
