LG W2230S-NF [19/22] Specifications
![LG W2230S-NF [19/22] Specifications](/views2/1085612/page19/bg13.png)
A18
Specifications W1930S
NOTE
Information in this document is subject to change without notice.
Display
Sync Input
Video Input
Resolution
Plug&Play
Power
Consumption
Dimensions
& Weight
Tilt Range
Power Input
AC-DC Adapter
Environmental
Conditions
Power cord
18.51 inches (47.01 cm) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
Visible diagonal size: 47.01 cm
0.300*0.300 mm pixel pitch
Horizontal Freq. 30 - 61 kHz (Automatic)
Vertical Freq. 56 - 75 Hz (Automatic)
Input Form Separate TTL, Positive/Negative
SOG (Sync On Green)
Signal Input 15 pin D-Sub Connector
Input Form RGB Analog (0.7 Vp-p/ 75 ohm)
Max VESA 1360 x 768 @ 60 Hz
Recommend VESA 1360 x 768 @60 Hz
DDC 2AB
On Mode
: 22W(Typ.)
Sleep Mode ≤ 1 W
Off Mode ≤ 1 W
Width 45.11 cm / 17.76 inches
Height 29.66 cm / 11.68 inches
Depth 5.13 cm / 2.02 inches
Net 2.3 kg (5.11 lbs)
Tilt 10˚~ 30˚
12V 2.0A
Type ADS-24S-12 1224G*,manufactured by HONOR Electronic
or type MU24-B120200-xx,manufactured by LEADER Electronics
or type LCAP07F,manufactured by Lien Chang
or Type ADS-24NP-12-1 12024G,manufactured by HONOR Electronic
Operating Conditions
Temperature 10˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Wall-outlet type
