![LG W2230S-NF [20/22] W2230s](/views2/1085612/page20/bg14.png)
A19
Specifications W2230S
NOTE
Information in this document is subject to change without notice.
Display
Sync Input
Video Input
Resolution
Plug&Play
Power
Consumption
Dimensions
& Weight
Tilt Range
Power Input
AC-DC Adapter
Environmental
Conditions
Power cord
21.53 inches (54.686 cm) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
Visible diagonal size: 54.686 cm
0.248*0.248 mm pixel pitch
Horizontal Freq. 30 - 83 kHz (Automatic)
Vertical Freq. 56 - 75 Hz (Automatic)
Input Form Separate TTL, Positive/Negative
SOG (Sync On Green)
Signal Input 15 pin D-Sub Connector
Input Form RGB Analog (0.7 Vp-p/ 75 ohm)
Max VESA 1920 x 1080 @ 60 Hz
Recommend VESA 1920 x 1080 @60 Hz
DDC 2AB
On Mode
: 25W(Typ.)
Sleep Mode ≤ 1 W
Off Mode ≤ 1 W
Width 52.12 cm / 20.52 inches
Height 33.90 cm / 13.35 inches
Depth 5.23 cm / 2.06 inches
Net 2.8 kg (6.22 lbs)
Tilt 10˚~ 30˚
12V 2.0A
Type LCAP07F,manufactured by Lien Chang
Operating Conditions
Temperature 10˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Wall-outlet type
