TOP QUALITY COMPONENTS
Together with high performance amplifiers, VERSE decided to put speakers
conceived specifically to do their best with a so remarkable reserve of power.
The woofer are made with neodymium magnets that allows the highest force
factor and excursion capability, and with ventilated voice coil gap for reduced
power compression. With such components it's easier to obtain huge
excursions, "present" and dynamic bass, high acoustic pressure and mild
weights.
DIGITAL PROCESSING
The processing system included in every D:SUB loudspeaker is based on a
performing DSP processor with PC-based remote control using dedicated
software. Sophisticated and innovative processing algorithms have been
implemented to ensure total protection of all system components without
sacrificing the dynamic of the sound source. Digital Limiters switch on when
transducers safety conditions or maximum amplifier power are going to be
exceeded, preventing the loudspeakers from being supplied with higher
volume input signals.
The processing unit includes as well a multi-band compressor, a delay line,
six full parametric equalizers and a dynamic loudness controller. The digital
delay line makes it possible to compensate for vertical alignment differences
between subwoofer and satellites or to create distributed lines of speakers
whose output reaches the listening point simoultaneously, eliminating echo
effects.
The multicomp processor and the Dynamic Loudness section can be extremely
useful for the system's dynamic EQ. While the Dynamic Loudness try to adapt
the output level according to the well known "Fletcher&Munson" curves, in
order to keep the original sound richness also at low level signals, the
Multicomp offers a more deep capability to modify and manipulate the
dynamic range of the audio signal.
A six band full parametric EQ may be used to tune the overall audio response
to the need: adapting the frequency response to the ambience, to the musical
genre or speaker voice, to the peculiar use of the moment, to personal tastes,
etc.
