POLE AND TRIPOD SAFETY RECOMMENDATION
This manual assumes that the owners and/or users of a VERSE System are
knowledgeable and experienced in the areas of Pole and Tripod use with
loudspeaker systems.
The suspension of large, heavy objects on Pole or Tripod in public places is subject
to numerous laws and regulations at the national/federal, state/provincial, and local
levels, that are not addressed in this manual.
However, the user must assume responsibility for making sure that use of any VERSE
system, its components and all the stands and poles and associated hardware in any
particular circumstance or venue conforms to all applicable laws and regulations in
force at the time.
WHEN USING STANDS OR POLES, BE SURE TO OBSERVE THE FOLLOWING
PRECAUTIONS.
CHECK THE STAND OR POLE SPECIFICATION TO BE CERTAIN THE DEVICE IS DESIGNED
TO SUPPORT THE WEIGHT OF THE SPEAKER. OBSERVE ALL SAFETY PRECAUTIONS
SPECIFIED BY THE MANUFACTURER.
MAKE SURE THAT THE SURFACE ON WHICH THE SYSTEM IS TO BE STACKED IS FLAT,
STABLE AND SOLID.
ROUTE CABLES SO THAT PERFORMERS, PRODUCTION CREW, AND AUDIENCE WILL
NOT TRIP AND TOPPLE THE SPEAKERS.
INSPECT THE STAND (OR POLE AND ASSOCIATED HARDWARE) BEFORE EACH USE AND
DO NOT USE EQUIPMENT WITH WORN, DAMAGED, OR MISSING PARTS.
DO NOT ATTEMPT TO PLACE MORE THAN ONE VERSE D:SIDER LOUDSPEAKERS ON A
STAND OR POLE.
ALWAYS BE CAUTIOUS WHEN DEPLOYING THE SYSTEM OUTDOORS. UNEXPECTED
WINDS MAY TOPPLE A SYSTEM.
IT MAY BE NECESSARY TO PLACE ADDITIONAL WEIGHT (I.E.SANDBAGS) ON THE BASE
OF THE STAND TO IMPROVE STABILITY. AVOID ATTACHING BANNERS OR SIMILAR
ITEMS TO ANY PART OF A SPEAKER SYSTEM. SUCH ATTACHMENTS COULD ACT AS A
SAIL AND TOPPLE THE SYSTEM.
UNLESS YOU ARE CONFIDENT THAT YOU CAN HANDLE THE WEIGHT OF THE
SPEAKER, ASK ANOTHER PERSON TO HELP YOU GET IT ONTO THE TRIPOD STAND OR
POLE.
Whenever the VERSE speakers are going to be installed on a tripod, make sure that
the system stability is granted, in order to avoid toppling. The stability is
determined by the speaker placement height and the legs spread. Provided that the
users are charged by responsibility of a correct installation and of a thorough
stability check, a reference for the setup may be the following: using a tripod with a
basis spread of at least 168cm, it is possible to place the speaker up to 180cm high.
