22
TASCAM UH-7000
5 – Mixer Panel Settings
8
EQ (3-band parametric Equalizer)
Use this to increase or decrease the levels of specific frequency
ranges. This can be used, for example, to enhance the sound
of individual instruments, to adjust the balance of a wide
frequency range and to cut specific unwanted frequencies.
The frequency response at the current settings is shown as a
graph even when the equalizer is off.
The equalizer has a high-shelf HIGH band, a low-shelf LOW band
and a peaking (bell-shaped) MID band.
LOW GAIN knob
Sets the amount the level is increased or decreased for
the LOW band.
Range: ±12 dB (default: 0 dB)
LOW FREQ knob
Sets the cutoff frequency of the LOW band.
Range: 32 Hz–1.6 kHz (default: 100 Hz)
MID GAIN knob
Sets the amount the level is increased or decreased for
the MID band.
Range: ±12 dB (default: 0 dB)
MID FREQ knob
Sets the cutoff frequency of the MID band.
Range: 32 Hz–18 kHz (default: 1.0 kHz)
MID Q knob
Sets the acuteness of the peak of the MID band.
The higher the value the more acute it becomes, making
it affect a narrower frequency band. The lower the value,
the less acute it becomes, making it affect a broader
frequency band.
Range: 0.25–16 (default: 0.5)
HIGH GAIN knob
Sets the amount the level is increased or decreased for
the HIGH band.
Range: ±12 dB (default: 0 dB)
HIGH FREQ knob
Sets the cutoff frequency of the HIGH BAND.
Range: 1.7 kHz–18 kHz (default: 10 kHz)
8
Limiter/Low cut filter
Set both the limiter and low-cut filter effects on this page.
The LIMITER adjusts the input gain in response to the analog
input level. This function reduces the recording level when loud
sounds are input to prevent distortion. The limiter function can
only be used on the analog inputs.
The LOW-CUT filter reduces the sounds of air-conditioning and
wind and other low-frequency noises that are easily picked up
by microphones.
FREQUENCY knob
Sets the cutoff frequency of the low-cut filter.
Options: 40 Hz, 80 Hz (default), 120 Hz
NOTE
•
When the sampling frequency is 44.1 kHz or 48 kHz, both
the limiter and low-cut filter functions can be used together
at the same time. When using the limiter and low-cut filter
functions at the same time, the send effect cannot be used.
•
The limiter can only be turned on and off. It does not have
any adjustable parameters.
Send effect
8
REVERB
This effect adds reverberations to the original sound. Multiple
sounds are delayed at various times with damping over time
that is as natural as possible to produce reverberations like
those of a hall, live-music club or studio, for example.
Reverb type switch
Use to select the type of reverb.
Depending on the type, the density and level of the
reverb sound changes.
Options: HALL (default), ROOM, LIVE, STUDIO, PLATE
PRE DELAY knob
Set the amount of delay until the first reverberations.
The larger the value, the larger the reverberations make
the room sound.
Range: 0–100 ms (default: 42 ms)
REVERB TIME knob
Set the amount of time that the reverberations continue.
The larger the value, the longer they continue.
Range: 0.1–10 s (default: 2.7 s)
