IF2108/IF2208
14
Specifications
*1: With recommended YAMAHA DSP configuration.
* 2: 2 hrs. IEC noise.
* Specifications and descriptions in this owner’s manual are for information purposes only. Yamaha Corp. reserves the right to change or modify products or specifications at any time without prior
notice. Since specifications, equipment or options may not be the same in every locale, please check with your Yamaha dealer.
* Die technischen Daten und Beschreibungen in dieser Bedienungsanleitung dienen nur der Information. Yamaha Corp. behält sich das Recht vor, Produkte oder deren technische Daten jederzeit ohne
vorherige Ankündigung zu verändern oder zu modifizieren. Da die technischen Daten, das Gerät selbst oder Sonderzubehör nicht in jedem Land gleich sind, setzen Sie sich im Zweifel bitte mit Ihrem
Yamaha-Händler in Verbindung.
* Les caractéristiques techniques et les descriptions du mode d’femploi ne sont données que pour information. Yamaha Corp. se réserve le droit de changer ou modifier les produits et leurs
caractéristiques techniques à tout moment sans aucun avis. Du fait que les caractéristiques techniques, les équipements et les options peuvent différer d’fun pays à l’fautre, adressez-vous au
distributeur Yamaha le plus proche.
* Las especificaciones y descripciones de este manual del propietario tienen sólo el propósito de servir como información. Yamaha Corp. se reserva el derecho a efectuar cambios o modificaciones en
los productos o especificaciones en cualquier momento sin previo aviso. Puesto que las especificaciones, equipos u opciones pueden no ser las mismas en todos los mercados, solicite información a
su distribuidor Yamaha.
*仕様および外観は改良のため予告なく変更することがあります。
System Type 2-way full-range speaker 2-way full-range speaker
Model IF2208(W) IF2108(W)
Specifications/Drive Mode Passive Passive
Frequency Range (-10dB) (4)
*1
55 Hz – 19k Hz 55 Hz – 19k Hz
Frequency Range (±3dB) (4)
*1
75 Hz – 18k Hz 75 Hz – 18k Hz
Nominal Coverage (H x V, -6dB) 90° x 60°, can be rotated to 60° x 90° 90° x 60°, can be rotated to 60° x 90°
Power Rating 200 W
*2
100 W
*2
Nominal Impedance 8 ohms 8 ohms
Sensitivity (1W@1m) 95dB SPL 95dB SPL
Calculated Peak SPL 124dB SPL 121dB SPL
Calculated Continuous SPL 118dB SPL 115dB SPL
Components
LF 2 x 8" (20cm) Woofer, 2" (50mm) Voice Coil 8" (20cm) Woofer, 2" (50mm) Voice Coil
HF
Rotatable Constant Directivity Horn, 1" (25mm) exit,
1.7" (44mm) Voice Coil Compression Driver
Rotatable Constant Directivity Horn, 1" (25mm) exit,
1.7" (44mm) Voice Coil Compression Driver
Enclosure
Dimensions (H x W x D) 673 x 283 x 250 mm (26.5 x 11.1 x 9.8 in) 448 x 283 x 250 mm (17.6 x 11.1 x 9.8 in)
Weight 19 kg (42 lbs) 14 kg (31 lbs)
Shape Multi-angle wedge Multi-angle wedge
Material 5/8 inch (16mm), 11-ply Finnish Birch 5/8 inch (16mm), 11-ply Finnish Birch
Finish Textured Black (Textured White) Textured Black (Textured White)
Grill
16 gauge powder coated perforated steel grilles, backed with
acoustically transparent reticulated foam
16 gauge powder coated perforated steel grilles, backed with
acoustically transparent reticulated foam
Connectors 2x Neutrik NL4 and barrier strip, wired in parallel 2x Neutrik NL4 and barrier strip, wired in parallel
Flying Hardware
11x M10 for shoulder eyebolts and U-bracket
6x M8 for 3rd party speaker mount hardware
11x M10 for shoulder eyebolts and U-bracket
6x M8 for 3rd party speaker mount hardware
Pole Mounts One One
Handle One One
Optional Accessory
U-bracket UB2208(W) UB2108(W)
Array Frame n/a n/a
3rd party accessory
Omnimount (US) 60.0 series 60.0 series
Multimount (US, Allen products) 020, 022 series 020, 022 series
Powermount (UK) 100 series 100 series
Ohashi (Japan) SPH-140, SPA-140, BCH-140 series SPH-140, SPA-140, BCH-140 series
