2
User guide addendum V2 for Ui24R
(firmware 1.8xxx)
V2 firmware represent major enhancements for the Ui24R.
Several features such as the patching system has been completely changed.
We encourage users to spend some time understand the flexibility (and the complexity it
bring with it).
Although no issues have been found using previous versions Snap shots and shows it is
recommended that these be tested in the new firmware and a new version saved.
Please back up any important files before any updates are done.
It is also recommended that once an update has been completed and the system requests
the user to reboot the Ui24R:
Switch the Ui24R OFF
Remove the power connection from the Ui24R (or turn it off at the power point)
Wait the 10 seconds
Switch the Ui24R back ON
Please note that the first time the Ui24R is rebooted after a firmware update the boot
sequence will take longer as new files are being generated.
Some of the new features include:
2 more Aux/Matrix sends (Aux 9 and 10)
4 more processing channels
Automix (2 groups)
Ducking and side chaining in Subgroups
New Patch Matrix
PRE POST FX sends
Various gui and function enhancements(as per release notes)
We have also added a new ‘BIG D’ (larger gui for displays with more
than 1200 pixels across).
Additional 25 HDMI USB VID PID touch screens supported
As well as a host of gui improvements and requested bug fixes.
The Smaller device (Phone) software does not included many of these features as they
cannot fit in the smaller screen format.
NOTE: Please load previous firmware shows and snapshots and re-save them with the
new firmware version. Many of the new features need to be added to the older snapshots
(such as the new patching system).
