Soundcraft Si Performer 1 [55/135] Acs elements

User Manual

7.2: ACS ELEMENTS

DSP ELEMENTS > ACS ELEMENTS

7.5: DSP ELEMENTS > ACS

The Assignable Channel Strip (ACS) follows the currently selected DSP Channel and provides al-

most all of the controls relating to that. It is broken down in to small colour coded sections making it

easy to identify control groups and functions at a glance.

There is a dedicated control for each function and each control has a dedicated label and scale, just as you would nd

on an analogue mixer

The exact value of any control will be shown on the Touch Screen using the Function Focus feature (see section 7.1)

as you adjust them.
