Shure UR4D+ J5E 578 - 638 MHz [32/50] L3e frequency band 638 00 698 00 mhz
![Shure UR4D+ J5E 578 - 638 MHz [32/50] L3e frequency band 638 00 698 00 mhz](/views2/2007976/page32/bg20.png)
86
Channel
Full Range
max. # of
comp. frequen-
cies (option 1)
Full Range
max. # of
comp. frequen-
cies (option 2)
France
preferred: User
Group A
(option 1)
France
preferred: User
Group A
(option 2)
France
preferred: User
Group B
(option 1)
France
preferred: User
Group B
(option 2)
France
preferred: User
Group C
(option 1)
France
preferred: User
Group C
(option 2)
All Bands All Bands
Group 1 Group 2 Group 3 Group 4 Group 5 Group 6 Group 7 Group 8 Group 9 Group 10
1 638.100 638.900 639.500 639.500 640.775 638.500 640.225 639.000 647.625 639.350
2 638.825 639.625 640.500 640.500 642.225 640.775 640.975 640.225 654.200 642.325
3 639.350 640.150 641.250 641.750 645.300 645.300 642.025 640.975 657.200 643.850
4 640.375 641.175 641.750 643.250 646.100 650.225 644.700 642.025 657.600 644.325
5 641.725 642.525 643.250 643.750 648.025 650.975 646.300 644.700 658.750 647.875
6 642.350 643.150 646.750 647.250 650.975 652.900 653.100 652.700 663.050 649.975
7 645.150 645.950 651.500 655.500 660.500 654.100 653.500 653.100 664.050 650.575
8 650.250 651.050 655.500 657.250 660.900 654.500 656.975 660.000 664.775
662.275
9 650.675 651.475 667.250 665.750 662.100 658.225 661.100 662.300 668.025 663.450
10 652.750 653.550 672.500 671.750 668.500 670.500 666.025 668.700 675.025 672.575
11 654.625 655.425 673.750 672.500 672.775 678.100 666.775 669.500 679.725 673.300
12 663.475 664.275 679.250 675.250 680.025 680.775 680.225 680.975 680.600 680.925
13 664.700 665.500 679.750 676.250 681.500 682.975 682.025 685.900 684.200 684.100
14 667.325 668.125 681.250 682.500 690.975 684.900 685.500 687.000 688.025 687.500
15 668.775 669.575 683.750 684.250 692.900 686.500 688.225 692.700 688.475 688.000
16 669.700 670.500 687.500 687.500 694.100 692.900 692.000 693.900 689.650 689.650
17 673.450 674.250 692.250 691.750 694.500 693.700 692.700 694.300 693.700 691.500
18 676.275 677.075 695.500 695.750 696.775 696.025 693.100 696.225 694.250 692.325
19 681.050 681.850 696.500 697.250 697.500 697.500 693.900 696.975 695.700 693.750
20 682.600 683.400 697.250 697.750 638.100 638.100 696.975 650.775 697.425 697.500
21
684.700 685.500 638.750 641.250 648.775 644.900 652.000 656.225 648.425 655.425
22 691.450 692.250 647.250 647.750 650.225 648.775 658.025 663.000 662.400 659.025
23 694.450 695.250 649.250 648.500 661.700 657.500 658.775 664.975 690.350 679.925
24 695.300 696.100 649.750 657.750 666.225 666.975 668.000 672.225 644.000 657.950
25 695.700 696.500 650.500 658.500 666.975 669.300 680.975 682.775 649.875 661.400
26 696.650 697.450 660.250 662.750 669.300 670.100 684.700 685.100 659.300 676.450
27 697.150 697.950 662.750 663.500 669.700 672.775 685.900 686.300 682.950 694.300
28 643.850 644.650 664.500 665.250 682.225 684.500 692.425 696.875
29 668.300 669.100 666.500 667.500 685.700 692.500 640.750 646.000
30 692.750 693.550 671.500 671.250 686.100 694.100 642.900 658.600
31 649.350 650.150 674.500 674.500 644.825 659.875
32 653.950 654.750 684.250 688.500 677.625 670.900
33 657.925 658.725 689.750 689.250 679.325 675.275
34 681.950 682.750 691.750 691.250 697.950 676.975
35 685.525 686.325
697.750 695.250
36 686.575 687.375
37 690.775 691.575
38 655.750 656.550
39 671.700 672.500
40 689.425 690.225
L3E FREQUENCY BAND (638.000 - 698.000 MHz)
