M5E FREQUENCY BAND (694–758 MHz) Continued
Group 11 Group 12 Group 13 Group 14 Group 15 Group 16 Group 17 Group 18 Group 19
Channel
France
preferred:
User Group C
694 - 758 MHz
(option 1)
France
preferred:
User Group C
694 - 758 MHz
(option 2)
France
preferred:
User Group C
694 - 758 MHz
(option 3)
European TV
channel 49
optimized
694 - 702 MHz
European TV
channel 50
optimized
702 - 710 MHz
European TV
channel 51
optimized
710 - 718 MHz
European TV
channel 52
optimized
718 - 726 MHz
European TV
channel 53
optimized
726 - 734 MHz
European TV
channel 54
optimized
734 - 742 MHz
1 694.300 698.025 694.300 694.350 702.350 710.350 718.350 726.350 734.350
2 695.000 700.700 701.900 694.700 702.700 710.700 718.700 726.700 734.700
3 712.975 703.000 706.025 695.375 703.375 711.375 719.375 727.375 735.375
4 714.775 704.975 708.000 696.700 704.700 712.700 720.700 728.700 736.700
5 719.000 709.500 711.000 697.175 705.175 713.175 721.175 729.175 737.175
6 722.775 710.300 712.225 698.400 706.400 714.400 722.400 730.400 738.400
7 724.700 728.225 727.000 699.825 707.825 715.825 723.825 731.825 739.825
8 725.900 732.000 732.700 700.600 708.600 716.600 724.600 732.600 740.600
9 736.225 733.100 733.500 701.725
709.725 717.725 725.725 733.725 741.725
10 741.100 740.700 738.025 701.050 709.050 717.050 725.050 733.050 741.050
11 744.975 742.300 746.775
12 749.500 754.025 749.900
13 750.300 757.100 750.300
14 757.100 757.500 756.700
15 698.025 695.000 696.225
16 704.225 696.225 698.775
17 706.025 698.775 700.000
18 708.000 706.025 700.700
19 708.700 714.775 702.300
20 711.000 722.025 712.975
21 717.500 732.700 714.775
22 733.100 735.000 720.975
23 742.300 736.225 724.700
24 744.225 738.775 735.000
25 746.775 740.000 736.225
25 748.000 752.225 744.975
27 752.975 752.975 751.000
28 756.000 754.775
Channel
Group 20 Group 21 Group 22 Group 23 Group 24
European TV
channel 55
optimized
742 - 750 MHz
European TV
channel 56
optimized
750 - 758 MHz
Combined UHF-R
M5E, -Q5 and -R9:
max. # of compatible
frequencies
(option 1)
Combined
UHF-R M5E, -Q5
and -R9: max.
# of compatible
frequencies
(option 2)
Belgium
preferred:
“VRT”
TV ch. 51+ 54
710 - 718 MHz +
734 - 742 MHz
1 742.350 750.350 694.400 694.675 710.825
2 742.700 750.700 695.450 695.775 711.525
3 743.375 751.375 695.875 696.300 712.675
4 744.700 752.700 697.150 697.225 715.650
5 745.175 753.175 697.550 698.975 716.125
6 746.400 754.400 698.600 699.350 717.025
7 747 825 755 825 699.425 700.900 717.400
8 748.600 756.600 701.500 701.225 735.175
9 749.725 757.725 702.025 701.950 737.175
10 749.050 757.050 702.350 703.700 737.775
11 703.775 704.225 738.825
12 704.800 706.875 740.950
13 706.300 708.700 741.650
14 711.500 710.900 713.100
15 713.450 713.475 734.850
16 714.700 713.950 735.700
17 716.425 715.200 711.850
18 718.700 715.750 716.425
19 719.000 716.750 738.150
20 719.750 717.275 740.075
21 720.050 721.475
22 722.275 722.225
23 724.275 723.900
24 725.125 727.450
25 726.875 730.700
26 727.250 731.375
27 728.300 731.800
28 729.050 734.650
29 732.525 735.525
30 733.275 736.600
31 737.150 737.225
32 738.750
