4.2 SB18 connection
The SB
1
8 subwoofer is equipped with
two
4
point
SpeakON
®
connectors.
The IN connector allows receiving the audio signal, whereas the LINK
connector allows routing it to another SB18 enclosure in parallel.
SB18 parallel connection is only possible with the LA8 amplified controller.
Refer to the SB18 user manual for connection to the LA4.
Internal pinout for
L
-
ACOUSTICS
®
subwoofers
SpeakON
®
points
1+
1
-
2+
2
-
Transducer connectors
LF +
LF
-
Not used
Not used
To cable SB18
subwoofers with the LA4 amplified controller:
Use an SP cable (SP5, SP10 or SP25) to connect one SB18 enclosure to each of the four LA4 output channels
Maximum of 4 SB18 per LA4
1 SB18 subwoofer can be connected to each output channel on the LA4.
CARDIOID mode
Connect the reversed subwoofer to OUT1 to use a cardioid preset.
Impedance load
8 Ω for 1 SB18
Connecting four SB18 to one LA4 with SP cables
SP
SP
SP
SP
IN LINK
SB18
