A: PRESET DESCRIPTION
The latest version
of each
PRESET
LIBRARY
user manual
s
are
downloadable
from
the L-ACOUSTICS
®
web site.
[KI]: full-range
To use the K1 line source in FULL-RANGE mode, in standalone configuration, or in EXTENDED mode, in combination
with the K1-SB or SB28 subwoofer enclosures.
LA8
Inputs / Outputs
Elements to connect Routing*
Accessible (
O
) and blocked (X)
parameters
Mute
Gain
Delay
Polarity
IN A
Input Signal A
IN_A
X
O
O
O
IN B
Input Signal B
IN_B
X
O
O
O
OUT 1
Left LF transducer
LF_A
O
X
X
X
OUT 2
Right LF transducer
LF_A
O
X
X
X
OUT 3
MF section
MF_A
O
X
X
X
OUT 4
HF section
HF_A
O
X
X
X
* Left/Right: as seen from the front face
* * IN: input signal. A, B: channel A, B. LF: low frequency transducer. MF: medium frequency transducer. HF: high frequency transducer.
[K1SB_X] and [K1SB_60]: low extension
To use the K1-SB enclosures in the EXTENDED mode of the KI system, combining K1 and K1-SB enclosures in
THROW configuration for [K1SB_X], or in CONTOUR configuration for [K1SB_60].
LA8
Inputs / Outputs
Elements to connect Routing*
Accessible (
O
) and blocked (X)
parameters
Mute
Gain
Delay
Polarity
IN A
Input Signal A
IN_A
X
O
O
O
IN B
Input Signal B
IN_B
X
O
O
O
OUT 1
K1
-
SB subwoofer
SB_A
O
X
X
X
OUT 2
K1
-
SB subwo
ofer
SB_A
O
X
X
X
OUT 3
K1
-
SB subwoofer
SB_A
O
X
X
X
OUT 4
K1
-
SB subwoofer
SB_A
O
X
X
X
* IN: input signal. A, B: channel A, B. SB: subwoofer enclosure.
[SB28_60]: standard subwoofer
To use SB28 subwoofers in STANDARD mode, as single elements or as an array in standard configuration.
LA8
Inputs/Outputs
Elements to connect Routing*
Accessible (O) and
locked (X) parameters
Mute
Gain
Delay
Polarity
IN A
Input signal A
IN_A
X
O
O
O
IN B
Input signal B
IN_B
X
O
O
O
OUT 1
S
ubwoofer
SB_A
O
O
O
O
OUT 2
Subwoofer
SB_A
O
O
O
O
OUT 3
Subwoofer
SB_B
O
O
O
O
OUT 4
Subwoofer
SB_B
O
O
O
O
* IN: input signal. A, B: channel A, B. SB: subwoofer.
