ARCSWIFO_UM_EN_1-0
w w w . l - a c o u s t i c s . c o m
5
55
5
2
22
2
SYSTEM
SYSTEMSYSTEM
SYSTEM
COMPONENTS
COMPONENTSCOMPONENTS
COMPONENTS
The system approach developed by L-ACOUSTICS
®
consists in offering a global solution that guarantee the highest and
most predictable level of performance at any step of loudspeaker system deployment: modeling, installation and
operation. A complete L-ACOUSTICS
®
system includes enclosures, amplified controllers, cables, rigging system and
software applications.
The main components of an ARCS
®
WIDE SYSTEM or ARCS
®
FOCUS SYSTEM are the following:
2.1 Loudspeaker enclosures
ARCS
®
WIDE Full-range (55Hz – 20kHz), 2-way passive, constant curvature WST
®
line source, 90° x 30°
ARCS
®
FOCUS Full-range (55Hz – 20kHz), 2-way passive, constant curvature WST
®
line source, 90° x 15°
SB18m High power subwoofer (down to 32Hz)
Loudspeaker system design
Sound design aspects are beyond the scope of this document. However, the various applications of the
system will be based on the operating modes presented in this document.
2.2 Powering and driving system
LA4 or LA8 Amplified controllers with DSP library and networking capabilities
LA-RAK Touring rack containing three LA8, for power, audio signals and network distribution
Operating instructions
Refer to the LA4, LA8 and the LA-RAK user manual.
2.3 Loudspeaker cables
DOSUB-LA8 Breakout cable, 1 x 8-point PA-COM
®
> 4 x 2-point SpeakON
®
DO cables (DO.7, DO10, DO25) 8-point PA-COM
®
loudspeaker cables of respective lengths of 0.7 m/2.3 ft,
10 m/32.8 ft, and 25 m/82 ft
SP cables (SP.7, SP5, SP10, SP25) 4-point SpeakON
®
loudspeaker cables of respective lengths of 0.7 m/2.3 ft,
5 m/16.4 ft, 10 m/32.8 ft and 25 m/82 ft
SP-Y1 Breakout cable for two passive enclosure
SpeakON
®
< 2 x SpeakON
®
Information about the connection of the enclosures to the amplifiers is given in this document.
Refer to the LA4, LA8 or LA-RAK user manual for detailed instructions about the whole cabling scheme,
including modulation cables and network.
2.4 Rigging elements
Rigging elements or procedures are not presented in this document.
Refer to the ARCS
®
WIDE/FOCUS SYSTEM rigging manual.
2.5 Software applications
SOUNDVISION 3D acoustical and mechanical modeling
LA NETWORK MANAGER Remote control and monitoring of amplified controllers
Using L
-
ACOUSTICS
®
software
Refer to the SOUNDVISION training and the LA NETWORK MANAGER tutorial.
