ARCS
ARCSARCS
ARCS
®
WIDE
WIDE WIDE
WIDE SYSTEM /
ARCS
ARCSARCS
ARCS
®
FOCUS
FOCUSFOCUS
FOCUS
SYSTEM
USER
USERUSER
USER
MANUAL
MANUALMANUAL
MANUAL
VERSION 1.0
ARCSWIFO_UM_EN_1-0
w w w . l - a c o u s t i c s . c o m
10
1010
10
APPENDIX
APPENDIX APPENDIX
APPENDIX A
AA
A:
: :
: PRESET DESCRIPTION
The latest version of each
PRESET
LIBRARY
and the corresponding
user manual
s
are downloadable from
the L-ACOUSTICS
®
web site.
[ARCS_WIFO]: full range
To use ARCS
®
WIDE/FOCUS enclosures in FULL-RANGE mode, as a line source in standalone configuration, or in LOW-
EXTENSION mode, as a line source in combination with SB18m subwoofers.
Inputs/Outputs
Elements
to connect
Routing *
Accessible (O) and blocked (X) parameters
Mute Gain Delay Polarity
IN A Input Signal A IN_A X O O O
IN B Input Signal B IN_B X O O O
OUT 1 ARCS
®
WIDE/FOCUS
PA_A O O O O
OUT 2 ARCS
®
WIDE/FOCUS
PA_A O O O O
OUT 3 ARCS
®
WIDE/FOCUS
PA_B O O O O
OUT 4 ARCS
®
WIDE/FOCUS
PA_B O O O O
* IN: input signal. A, B: channel A, B. PA: passive enclosure.
[ARCS_WIFO_FI]: full range fill
To use ARCS
®
WIDE/FOCUS enclosures in FULL-RANGE mode, as single elements in standalone configuration, or in
LOW-EXTENSION mode, as single elements in combination with SB18m subwoofers.
Inputs/Outputs
Elements
to connect
Routing *
Accessible (O) and blocked (X) parameters
Mute Gain Delay Polarity
IN A Input Signal A IN_A X O O O
IN B Input Signal B IN_B X O O O
OUT 1 ARCS
®
WIDE/FOCUS
PA_A O O O O
OUT 2 ARCS
®
WIDE/FOCUS
PA_A O O O O
OUT 3 ARCS
®
WIDE/FOCUS
PA_B O O O O
OUT 4 ARCS
®
WIDE/FOCUS
PA_B O O O O
* IN: input signal. A, B: channel A, B. PA: passive enclosure.
[SB18_60]: standard
To use SB18m subwoofers in STANDARD mode, as a single elements or within an array in standard configuration.
Inputs/Outputs Elements to connect Routing*
Accessible (O) and locked (X) parameters
Mute Gain Delay Polarity
IN A Input signal A IN_A X O O O
IN B Input signal B IN_B X O O O
OUT 1 Subwoofer SB_A O O O O
OUT 2 Subwoofer
SB_A O O O O
OUT 3 Subwoofer
SB_B O O O O
OUT 4 Subwoofer
SB_B O O O O
* IN: input signal. A, B: channel A, B. SB: subwoofer.
[SB18_60_C]: cardioid
To use SB18m subwoofers in CARDIOID mode, as an array in cardioid configuration.
Inputs/Outputs Elements to connect Routing*
Accessible (O) and blocked (X) parameters
Mute Gain Delay Polarity
IN A Input signal A IN_A X O O O
IN B Input signal B IN_B X O O O
OUT 1 Reversed subwoofer SR_A O X X X
OUT 2 Subwoofer SB_A O X X X
OUT 3 Subwoofer
SB_A O X X X
OUT 4 Subwoofer
SB_A O X X X
* IN: input signal. A, B: channel A, B. SB: subwoofer. SR: reversed subwoofer.
