SPECIFICATIONS

SUB 9007-AS SUB 9006-AS SUB 9004-AS

ACOUSTICAL

Operating frequency response 20 Hz- 400 Hz 30 Hz - 400 Hz 30 Hz - 400 Hz

Max SPL 141 dB 142 dB 136 dB

Hi-Pass Frequencies 25Hz, 35Hz 30Hz, 40Hz 35Hz, 50Hz

Low-Pass Frequencies Variable from 50Hz to 400Hz Variable from 50Hz to 400Hz Variable from 50Hz to 400Hz

TRANSDUCERS

Low frequency 2 x 21”, 4.0” v.c. 2 x 18”neo, 4.0” v.c. 18” neo, 4.0” v.c.

AMPLIFIER

Total power 7200 W Peak, 3600 W RMS 7200 W Peak, 3600 W RMS 2800 W Peak, 1400 W RMS

CONNECTIONS

Signal input/output XLR, RDNet Ethercon XLR, RDNet Ethercon XLR, RDNet Ethercon

Power input/output Powercon IN/OUT Powercon IN/OUT Powercon IN/OUT

PROCESSOR

Controls Gain, EQ, Xover, Phase switch,

Output Delay Settings, Cardioid

Gain, EQ, Preset, Phase switch,

Output Delay Settings

Gain, EQ, Preset, Phase switch,

Output Delay Settings

Protections Thermal, RMS Thermal, RMS Thermal, RMS

Limiter Fast Limiter Fast Limiter Fast Limiter

PHISICAL SPECIFICATIONS

Cabinet material Baltic Birch Plywood Baltic Birch Plywood Baltic Birch Plywood

Hardware Mounting points, 2 x M20 2 x M20 2 x M20

Net Weight 96 Kg 86 Kg 57 Kg

Dimensions (w, h, d) 1135, 825, 760 mm 1188, 785, 558 mm 700, 558, 700 mm
