41
ONBOARD DIGITAL MIXER
SPECIFICATIONS
Nominal Output Level Main Out +4 dBu
Aux Send +4 dBu
Maximum Output Level Main Out 18,8 dBu
Aux Out 18,8 dBu
Output Impedance Aux Out 150 Ohm
Input Impedance Line In 10 KOhm
XLR In 3,4 KOhm
TRS In 11 KOhm
HiZ In 1 MOhm
Equivalent Input Noise dB
-114
Input HPF cutoff from 20Hz to 1kHz
Eq High @ 6 kHz ±12 dB
Mid sweepable (50Hz – 12kHz) ±12 dB
Low @ 125Hz ±12 dB
Frequency Response ±0.5 dB 20-20kHz
Bit Depht 24 bit
sample rates 44.1 / 48 kHz
Internal Effects DSP 32 bit floating point
Mic Input 4
Phantom Power
yes (Ch 1-2)
Mono Line Input
4
Stereo Line Input
2
Selectable Hiz Inputs
1
Compressors
4 (Ch 1-4)
Aux Output
1
USB Device
1
Internal Fx
1 x Z-CORE DSP FX
Hipass Filter
All channels from 20Hz to 1kHz
Eq for Mono Channels
3 bands (Shelving High and Low, Semi-parametric Mid)
Eq for Stereo Channel
3 bands (Shelving High and Low, Semi-parametric Mid)
Aux
1 (pre/post)
Fx to Aux
1
Aux Master
1
