K-ARRAY KP102 [21/24] Acoustics
![K-ARRAY KP102 [21/24] Acoustics](/views2/2008074/page21/bg15.png)
REV. A
KP52/KP102
21
KP102
Acoustics
Speakers power handling 720 W
(AES)
Max power 1200 W
1
Impedance 4Ω or 16Ω (selectable)
Frequency range 100 Hz - 20 KHz.
SPL 1W / 1mt 99 dB
2
Maximum SPL 128 dB continuous - 134 dB peak
Coverage
Horizontal 90°
Vertical 7°- 30° (selectable)
Crossover
Type External Crossover required
Frequency High pass @100 Hz, 24 dB/oct suggested minimum
Transducers
Full range 12 x 3.15” Neodymium magnet with 1” voice coil
Power Audio Input
Connectors 2 x 4-pin Speakon
Wiring 1+ 1-
(signal IN & LINK); 2+ 2- (through)
Selection Switch
Vertical pattern Spoot - Flood
Impedance 4Ω - 16Ω
Physical
Dimensions 8.8 x 100 x 11.8 cm (3.56” x 39.4” x 4.65”)
Weight 12 kg (26.45 lbs)
1. Maximum RMS applicable power for a musical signal, the
reference signal is the one proposed by EIAJ standard.
2. Measured @4 mt then scaled @1 mt
New materials and design are introduced into existing
products without previous notice. Present systems may differ
in some respects from those presented in this brochure.
