DTS FOS 100 SOLO POWER CT WIDE lens [26/32] Function
![DTS FOS 100 SOLO POWER CT WIDE lens [26/32] Function](/views2/2008099/page26/bg1a.png)
26
WALL MODE
1 GREEN
2 RED
3 BLUE
4 DIMMER
5 NOT USED
6 SHUTTER
DMX CHANNEL
1
Parameter:
GREEN
DMX range
Value
Mid Point DMX
value
Move Range
(degrees)
Mode
Option
Function
000
-
255
Proportional
colour
DMX CHANNEL
2
Parameter:
RED
DMX range
Value
Mid Point DMX
value
Move Range
(degrees)
Mode
Option
Function
000
-
255
Proportional
colour
DMX CHANNEL
3
Parameter:
BLUE
DMX range
Value
Mid Point DMX
value
Move Range
(degrees)
Mode
Option
Function
000
-
255
Proportional
colour
DMX CHANNEL
4
Parameter:
DIMMER
DMX range
Value
Mid Point DMX
value
Move Range
(degrees)
Mode
Option
Function
000
-
255
Proportional
dimmer
DMX CHANNEL
5
Parameter:
NOT USED
DMX range
Value
Mid Point DMX
value
Move Range
(degrees)
Mode
Option
Function
000
-
255
Unused
DMX CHANNEL
6
Parameter:
SHUTTER / STROBE
DMX range
Value
Mid Point
DMX
value
Move Rang
e
(degrees)
Mode
Option
Function
000
-
009
Black
-
out
010
-
019
Open
020
-
029
Black
-
out
030
-
119
Strobe (from 3.27 s to 30 ms)
120
-
149
Pulse up (from 42.6 s to 120 ms)
150
-
179
Pulse down (from 42.6 s to 120 ms)
180-204
Random s
trobe
(Dimmer channel active)
205-229
Full independent Random Strobe
(Dimmer channel disabled)
230
-
234
Red, Yellow, Cyan and Blue colour
effects at variable speed
235
-
255
Open
