6
Product codes:
03.LB030S.26.FW10 FOS 100 POWER SOLO IP20 FULLWHITE NARROW GREY SILVER
03.LB030S.26.FW25 FOS 100 POWER SOLO IP20 FULLWHITE MEDIUM GREY SILVER
03.LB030S.26.FW40 FOS 100 POWER SOLO IP20 FULLWHITE WIDE GREY SILVER
03.LB030S.FW10 FOS 100 POWER SOLO IP20 FULLWHITE NARROW BLACK
03.LB030S.FW25 FOS 100 POWER SOLO IP20 FULLWHITE MEDIUM BLACK
03.LB030S.FW40 FOS 100 POWER SOLO IP20 FULLWHITE WIDE BLACK
03.LB030S.F10 FOS 100 POWER SOLO IP20 FULLRGBW NARROW BLACK
03.LB030S.F25 FOS 100 POWER SOLO IP20 FULLRGBW MEDIUM BLACK
03.LB030S.F40 FOS 100 POWER SOLO IP20 FULLRGBW WIDE BLACK
03.LB030S.T10 FOS 100 POWER SOLO IP20 RGBW NARROW BLACK
03.LB030S.T25 FOS 100 POWER SOLO IP20 RGBW MEDIUM BLACK
03.LB030S.T40 FOS 100 POWER SOLO IP20 RGBW WIDE BLACK
03.LB031S.26.FW10 FOS 100 POWER SOLO IP65 FULLWHITE NARROW GREY SILVER
03.LB031S.26.FW25 FOS 100 POWER SOLO IP65 FULLWHITE MEDIUM GREY SILVER
03.LB031S.26.FW40 FOS 100 POWER SOLO IP65 FULLWHITE WIDE GREY SILVER
03.LB031S.FW10 FOS 100 POWER SOLO IP65 FULLWHITE NARROW BLACK
03.LB031S.FW25 FOS 100 POWER SOLO IP65 FULLWHITE MEDIUM BLACK
03.LB031S.FW40 FOS 100 POWER SOLO IP65 FULLWHITE WIDE BLACK
03.LB031S.F10 FOS 100 POWER SOLO IP65 FULLRGBW NARROW BLACK
03.LB031S.F25 FOS 100 POWER SOLO IP65 FULLRGBW MEDIUM BLACK
03.LB031S.F40 FOS 100 POWER SOLO IP65 FULLRGBW WIDE BLACK
03.LB031S.T10 FOS 100 POWER SOLO IP65 RGBW NARROW BLACK
03.LB031S.T25 FOS 100 POWER SOLO IP65 RGBW MEDIUM BLACK
03.LB031S.T40 FOS 100 POWER SOLO IP65 RGBW WIDE BLACK
03.LB031.26.FW10 FOS 100 POWER IP65 FULLWHITE NARROW GREY SILVER
03.LB031.26.FW25 FOS 100 POWER IP65 FULLWHITE MEDIUM GREY SILVER
03.LB031.26.FW40 FOS 100 POWER IP65 FULLWHITE WIDE GREY SILVER
03.LB031.FW10 FOS 100 POWER IP65 FULLWHITE NARROW BLACK
03.LB031.FW25 FOS 100 POWER IP65 FULLWHITE MEDIUM BLACK
03.LB031.FW40 FOS 100 POWER IP65 FULLWHITE WIDE BLACK
03.LB031.F10 FOS 100 POWER IP65 FULLRGBW NARROW BLACK
03.LB031.F25 FOS 100 POWER IP65 FULLRGBW MEDIUM BLACK
03.LB031.F40 FOS 100 POWER IP65 FULLRGBW WIDE BLACK
03.LB031.T10 FOS 100 POWER IP65 RGBW NARROW BLACK
03.LB031.T25 FOS 100 POWER IP65 RGBW MEDIUM BLACK
03.LB031.T40 FOS 100 POWER IP65 RGBW WIDE BLACK
5- MAIN ELECTRICAL CHARACTERISTICS (FOS 100 POWER SOLO)
Input Voltage Range : Vin 90 - 260 Vac
Frequency : 50 / 60 Hz
Power Consumption Range : 10 - 200 W
Power Factor (Pf) : 0.95 electronic PFC controller
Efficiency : 90% typical
Control Input:
Control Signal : DMX 512
Dimming System : Constant Current PWM
Address Range : DMX 512 channels addressable by display
