11
8- INPUT / OUTPUT CONNECTIONS
FOS 100 POWER SOLO (IP20)
Mains 90-260 V AC
50-60 Hz input Powercon
Female panel connector
DMX IN/OUT
XLR 5 pins Male / Female
Panel Connectors
Mains 90-260 V AC
50-60 Hz output Powercon
Female panel connector
MAX load:
230 V AC
= 10 FOS 100 POWER SOLO
100 V AC = 5 FOS 100 POWER SOLO
M16 LED input
Male cable connector
M16 LED output
Female panel connector
