1- SYMBOLS
Graphic symbols used on this manual
THIS SYMBOL INDICATES A HOT SURFACE
THIS SYMBOL INDICATES ELECTRIC SHOCK RISK
THIS SYMBOL INDICATES GENERAL RISK
THIS SYMBOL MEANS “DO NOT PLACE THE UNIT
ON INFLAMMABLE SURFACES”
THIS SYMBOL INDICATES THE MINIMUM
DISTANCE TO BE KEPT BETWEEN THE DEVICE
AND THE LIT OBJECT
2- GENERAL WARNING
Read the instruction contained in this user manual carefully, as they give important
information regarding safety during installation, use and maintenance.
The device is not for domestic use and must be installed by a qualified electrician or
experienced person.
Always disconnect the device from the mains before maintenance.
The device must always be equipped with an efficient ground connection.
3- GENERAL WARRANTY CONDITIONS
The unit is guaranteed for 36 months from the date of purchase against manufacturing
material defects.
F
!
10cm
Содержание
- Fos 100 power solo fos 100 power 1
- Made in italy 1
- User s manual rel 1 gb d t s illuminazione s r l italy http www dts lighting it 1
- Main electrical characteristics fos 100 power solo input voltage range vin 90 260 vac frequency 50 60 hz power consumption range 10 200 w power factor pf 0 5 electronic pfc controller efficiency 90 typical control input control signal dmx 512 dimming system constant current pwm address range dmx 512 channels addressable by display 6
- Product codes 6
- Input output connections fos 100 power solo ip20 11
- Display functions the fos 100 power solo display panel shows all the available functions using these functions it is possible to change some of the parameters and add some functions changing the d t s setting can vary the functions of the unit so that it does not respond to the dmx 512 signal used to control it carefully follow the instructions below before carrying out any variations or selections note the symbol shows which key has to be pushed to obtain the desired function 16
- Software version 4 16
- Dmx protocol 10 channels mode 1 shutter 2 dimmer 3 red 4 green 5 blue 6 white 7 white pre programmed whites at different colour temperatures 8 ctc 9 colours macro 10 functions 22
- Function 22
- Function 23
- Function 24
- Channels mode 1 shutter 2 dimmer 3 red 4 green 5 blue 6 white 25
- Function 25
- Function 26
- Wall mode 1 green 2 red 3 blue 4 dimmer 5 not used 6 shutter 26
- Channels mode m4ch 1 dimmer 2 red 3 green 4 blue 5 white 27
- Function 27
- Channel mode 1ch 1 dimmer 28
- Channels mode rgbw 1 red 2 green 3 blue 4 white 28
- Function 28
- D t s products are designed and manufactured at the d t s plants in italy 32
- D t s quality system 32
- Is certified to the iso 9001 2008 standard 32
- Iso 9001 2008 32
- Made in italy 32
