Features:
• EVS-18K 18-inch Woofer provides extended
low-frequency output
• 40 Hz to 200 Hz frequency range
• 96 dB SPL sensitivity, 128 dB max. SPL
• 400 W continuous, 1600 W peak power
• 15 mm Plywood Enclosure
Engineering Data Sheet
A 118
18-inch passive subwoofer
Wir weisen ausdrücklich darauf hin, dass bei
gehängten Lautsprecherboxen die einschlägigen
Sicherheitsbestimmungen zu beachten sind. Es
muss unbedingt qualifizierte Fachberatung in
Anspruch genommen werden!
We expressly point out that the relevant safety
regulations must be observed for “flying”
loudspeaker systems. It is imperative that quali-
fied expert advice is sought.
Order No. A118: F01U270187
Cabinet Subwoofer
Nominal impedance 8 Ohms
Minimum impedance 6.7 Ohms
Power Handling
continuous 400 W
program 800 W
peak 1600 W
Max. SPL (calculated with peak
power)
128 dB
Axial Sensitivity 96 dB
Frequency Range (-10 dB) 40 Hz to 200 Hz
Frequency Response (-3 dB) 50 Hz to 100 Hz
Recommended HP Frequency 30 Hz
Coverage (Horizontal x Vertical) Omnidirectional
LF Transducer 1 x EVS-18K, 457 mm (18“),
F01U250964
Connectors 2 x NL4-type
Enclosure Material 9-ply, 15 mm Plywood, internally braced,
with textured paint
Grille 18-GA Steel with black powdercoat
Product Dimensions (H x W x D) 661 x 507 x 574 mm
Shipping Dimensions (H x W x D) 738 x 575 x 642 mm
Net Weight 30.6 kg
Shipping Weight 37.3 kg
Warranty 5 years
Optional Accessories
SH-A118, Dust Cover F01U270397
Recommended extensions
A 112 12“ full-range cabinet F01U270185
A 115 15“ full-range cabinet F01U270186
