6. Input 1 (Mono)

Use this jack when only a single connection is needed. Connect your instrument, the output of a

pedal, or an amp effects send to this jack. Signals are heard at both outputs when only this jack is

used.

7. Indicator LED

This LED lights red to indicate when the effect is turned on.

8. Input 2

Connect a second input to this jack for stereo operation. Inputs 1 and 2 are processed separately

through the effect then fed to Outputs 1 and 2, keeping true stereo separation between channels.

9. Footswitch

Turns the effect on or off.

10. SPEED Knob

Controls the rate of the modulation effect. Turn the knob clockwise to increase the rate or counter-

clockwise to decrease the rate.

The Ventura Vibe gives you the flexibility to control the speed of the modulation effect during

performance by pressing and holding the Footswitch while the effect is on. The Vibe’s LED will

turn green and the speed will ramp up to the fastest speed for the selected type as long as the

footswitch is held. When the Footswitch is released, the LED will turn red again and the speed will

return to the speed set by the SPEED knob.

11. MIX Knob

Controls the amount of effect added to the dry (unprocessed) signal. Turn this knob clockwise for

more effect or counter-clockwise for less effect.

12. Output 1 (Mono)

Connect this output to the input of a single guitar amplifier or amp effects return.

13. Output 2

Connect this output to the input of a second guitar amplifier when a second amp is being used.

When only the Input 1 (Mono) jack is connected, guitar and effect signal can be heard in both

Outputs 1 and 2 when they are used.
