Key Features:
• Practically indestructible in normal use
• Steel housing provides magnetic shielding
and strength
• Withstands humidity, salt air, and severe
mechanical shocks
• Self generating, no powering required
• Uniform 80-13,000 Hz response
Technical Specifications:
:tnemelEnoitareneGcimanyD
:esnopseRycneuqerF)trahcees(zH000,31otzH08
:nrettaPraloPlanoitceridinmO
:)woL(ecnadepmIsmho051
tiucriCnepO,ytivitisneS
:zHk1,egatloV
lacsaP/Vm4.1
:ytiraloPhtiw3nipotdecnerefer,evitisop2niP
mgarhpaidnoerusserpevitisop
:lairetaMesaCleetS
:hsiniFegieBnwaFA536
kcalBssolG-imeSB/A536
:dedulcnIseirosseccAretpadAdnatS113
:seirosseccAlanoitpOneercsdniWE413
dnatSkseDA224
:snoisnemiD)"49.5(mm151=htgneL
)"14.1(mm63=retemaiD
:thgieWteN).zo6(smarg071
:thgieWgnippihS).zo61(smarg454=ciMelgniS
635A & 635A/B
Dynamic
Omnidirectional
Microphones
General Description:
The Electro-Voice® 635A and 635A/B are designed
for exacting professional applications such as film
production, recording, broadcasting, and the more
demanding PA applications. The high output level,
and low sensitivity to mechanical shock, make the 635A
and 635A/B excellent for interviews and for pass-around
use in audiences. The 635A and 635A/B feature a
diaphragm which permits very smooth response over
a wide frequency range. The diaphragm withstands
humidity and temperature extremes, corrosive effects
of salt air, and severe mechanical shocks. It is
practically indestructible with normal use. A four-stage
pop and dust filter ensures a completely pop-free
performance and virtually eliminates the need for an
external windscreen during outdoor use. An internal
shock absorber effectively reduces the pickup of cable
and other noise generated by external contact.
Содержание
- A 635a b 1
- Dynamic omnidirectional microphones 1
- General description 1
- Key features 1
- Practically indestructible in normal use 1
- Self generating no powering required 1
- Steel housing provides magnetic shielding and strength 1
- Technical specifications 1
- Uniform 80 13 000 hz response 1
- Withstands humidity salt air and severe mechanical shocks 1
- Architects and engineers specifications 2
- Dimension drawing 2
- Frequency response 2
- Portland avenue south burnsville mn 55337 phone 952 884 4051 fax 952 884 0043 2
- The microphone shall be an electro voice 635a or 635a b the microphone shall be an omnidirectional dynamic type with wide range response uniform from 80 13 000 hz it shall have a four stage pop filter and magnetic shield to prevent dust and magnetic particles from reaching the diaphragm the impedance shall be such that the microphone will match 50 150 and 250 ohm inputs the line shall be balanced to ground and phased the output level shall be 55 db with 0 db equaling 1 mv pascal the magnetic circuit shall be a nonwelded circuit and employ alnico v and magnetic iron the case shall be made of steel the microphone shall have a maximum diameter of 36 mm 1 1 in a length of 151 mm 5 4 in and a weight of 170 grams 6 oz the electro voice 635a and 635a b are specified 2
- Wiring diagram 2
- Www electrovoice com 2
