Digitech Ventura Vibe [4/13] User interface

USER INTERFACE

S P EED D EPTH

MIX T ONE DR IVE

1 2

612

813

1. Effect Type Selector Switch

Selects from the following vibrato/rotary algorithm types:

• VINTAGE - The classic sound of a vintage vibrato effect (based on the classic Uni-Vibe®)

• MODERN - A modern vibrato effect.

• ROTARY - Effect based on the sound of a rotating Leslie® speaker cabinet.

2. DC Power Jack

Connect the specified HARMAN power supply (sold separately) to this jack. Be sure to use the

proper power supply for your area’s mains line voltage. See ‘Specifications’ on page 10 for power

supply model information. The Ventura Vibe can only be powered using the external power supply.

3. DEPTH Knob

Increases the intensity of the modulation effects. Turn the knob clockwise to increase the intensity

and counter-clockwise to decrease the intensity.

4. TONE Knob

This knob is used to increase or decrease the amount of high frequencies in the effect signal. Turn

the knob clockwise to increase the high frequencies or counter-clockwise to decrease the high

frequencies. With the knob at the 12 o’ clock position, there is no boost or cut of high frequencies.

5. DRIVE Knob

This knob is used to increase or decrease the amount of drive/distortion incorporated into the

effect. Turn the knob clockwise to increase the drive/distortion amount or counterclockwise to

reduce the drive/distortion amount.
