DETAILED coMponent descriptions

2.1 | R300 Receiver

RECEIVER CONTROLS, CONNECTORS

1.PowerON/OFF

2.SYNCDataTransferButton

3.InfraredEZsyncWindow

4.GraphicalDisplay

 a.ChannelorFrequencyDisplay

 b.DiversityIndicator

 c.RFStrengthMeter

 d.AudioLevelMeter

 e.LockIndicator

 f.SquelchLevelIndicator

5.ScrollDownandUp(

and )ControlButtons

6.SETControlButton

7.ClearScanControl(pressandhold button)

8.TNCAntennaInputConnectors(2)

9.BalancedOutputVolumeControl

10.XLRBalancedOutputConnector

11.¼InchUnbalancedLineLevelAudioOutputConnector

12.UnbalancedOutputLevelSwitch(-10dBor0dB)

13.DCPowerConnector(12VDC,500mA)

14.PowerCordRetainer

8 89 10

12 13 14
