Page 8 of 10 Nimbus™ User Manual Rev. 9
4. OPERATION
Basic
Instructions
• The top plate has two LED indicators –
one red and one green. The red LED
indicates that the heater is on, and the green LED indicates when the water is at its
optimal operating temperature. The heater will not turn on unless
there is enough
water.
•
As the dry ice sublimates, the green LED indicator will turn off indicating that the
water temperature has dropped below its optimal operating temperature. This is
normal and the Nimbus™ will continue to operate until all the dry ice has been used.
• During operation, the top plate becomes very hot. DO NOT TOUCH!
•
There is an optional power input next to the main power input to increase the rate in
which the water is heated. Use the included power cable and connect this secondary
input t
o a separate circuit to heat the water in half the time. Do not plug both power
cords into the same circuit as the breaker will trip.
• The dry ice must be stored inside the internal basket for optimal performance. Do not
remove this basket as serious bodily injury may occur.
Operation
1. Place the machine on a level surface. Plug the power cord into the wall.
2. Raise the basket to its highest level with the operation lever.
3. Open the lid and fill with water until the red light comes on. The container can hold up
to 4.5 gallons (17 liters).
4.
Using protective gear, load the basket with up to 10 lbs of dry ice. The dry ice should
be loaded at the last possible moment.
5. Close and latch the lid.
6. Grab the operating lever and slowly lower the handle to the middle notch
for low
output or all the way down for high output.
7. When output slows or stops, raise and refill the basket.
Due to water evaporation, you may need to refill the Nimbus™ with water to trigger the
red LED indicator. Once the red light comes on, repeat steps 4 through 7.
Safety Shutoff
Feature
The Nimbus™ is fitted with a safety shutoff feature, which
prevents the unit’s heaters
from turning on when the water level is too low. If this safety shutoff feature has been
engaged, simply add more water to continue using the Nimbus™.
5. TECHNICAL INFORMATION
Maintenance
The Nimbus requires minimal upkeep in order to maintain optimum performance.
However, some steps are needed in order to clean and maintain the product for
maximum usage. The recommended procedure is as follows:
1. After use, wait for the machine and any remaining water inside to fully cool down.
2. Dump all cooled water from the internal tank from the product. You may risk bodily
harm and damage to transport items if the water is still hot.
