Digitech JamMan Solo XT [44/72] Recording loops sequentially using jamsync
![Digitech JamMan Solo XT [44/72] Recording loops sequentially using jamsync](/views2/2008318/page44/bg2c.png)
38
Recording Loops Sequentially Using JamSync
To record loops to a master and slave sequentially using JamSync:
1. Select an empty memory location in
each JamMan Solo XT device using the
<UP/DOWN> buttons (LOOP and
SINGLE LEDs will be off).
2. If you wish to play to the Rhythm
Guide Track (optional), tap the master
device’s <TEMPO> button a few
times at the rate you want the phrase
tempo to be. You will begin to hear
the Rhythm Guide Track and the beats
will be indicated by a flashing TEMPO
button LED. When using the Rhythm
Guide Track, time signature can be
manually set to another time signature
other than the default 4 beats per
measure (see “Time Signature” on page
45
).
3. Press the <PEDAL SWITCH> on the
slave device. This will arm the slave for
recording, indicated by a flashing red
STATUS LED.
4. Press the <PEDAL SWITCH> on the
master device to initiate recording
and begin playing. If you set a tempo in
step 2, you will receive a one measure
count in, indicated by a flashing red
and green STATUS LED. After the
count in, begin playing with the first
beat to start recording. Recording will
be indicated by a solid red STATUS
LED.
5. As soon as you’re done recording,
press the <PEDAL SWITCH> again
to stop recording and initiate playback.
At the same time, the slave device will
begin recording, indicated by a solid
red STATUS LED. Play the phrase
you would like recorded in the slave
device.
