3
EN
QUICK REFERENCE GUIDE
SlimPAR Pro QZ12 USB QRG Rev.2
Menu Map
DMX Linking
The SlimPAR Pro QZ12 USB can work with a DMX controller. Instructions for connecting and configuring this product for
DMX operation are in the User Manual. If you are not familiar with DMX or dip switch configuration, download the DMX
Primer from www.chauvetdj.com.
Starting Address
To ensure full access to all channels available in DMX mode, the highest recommended DMX address is 502.
Master/Slave Connection
The SlimPAR Pro QZ12 USB uses the DMX data connection for its Master/Slave made. Instructions for connecting and
configuring this product for Master/Slave operation are in the User Manual.
MAIN LEVEL PROGRAMMING LEVELS DESCRIPTION
5-CH d 1--512 5-channel DMX mode
6-CH d 1--512 6-channel DMX mode
11CH d --512 11-channel DMX mode
C-- C1--15 Static colors
ZOOM Z 0--255 Zooms in and out
P--
(automatic)
P1 5-color program (snap)
P2 5-color program (fading)
P3 11-color program (snap)
P4 11-color program (fading)
S-- S--1–100 Program speed for P1–P4
Snd
(sound-active)
Snd1 4-color program (sound-active)
Snd2 11-color program (sound-active)
Sens u--0–100 Sound sensitivity
U--
A000–255
(amber)
Custom static colors. Combine amber,
red, green, and blue
r000–255
(red)
g000–255
(green)
b000–255
(blue)
dIM
OFF
Dimmer speed settings
dIM1
dIM2
dIM3
TEMP XX
Displays the current temperature of the
product
