• Determine the position where the ClickMount will be mounted

on the wall. Please allow a minimum distance of 105 mm for

MASK6C and 50 mm for MASK4C between the top of the

ClickMount and the ceiling is necessary when installing the

speaker in the upright position. The cable entry point is 95mm

below the top of the bracket. The cable can enter from the

rear of the bracket so that it is completely hidden from view.

The ClickMount MUST be mounted with the arrows facing

upwards!

• Now mark the four mounting holes on the wall. Use the built-in

spirit level for correct positioning of the ClickMount unit.

Drill the mounting holes and attach the ClickMount in place using

adequate hardware. Use only hardware capable of supporting the

speaker’s weight safely. Be careful when you drill the holes in the

wall: make sure not to drill into the speaker cables or other objects

hidden inside the wall.
