User Instructions
ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 2
Quad Phase HP General Information
Unpacking: Thank you for purchasing the Quad Phase HP by ADJ
Products, LLC. Every Quad Phase HP has been thoroughly tested and
has been shipped in perfect operating condition. Carefully check the
shipping carton for damage that may have occurred during shipping.
If the carton appears to be damaged, carefully inspect your xture for
any damage and be sure all equipment necessary to operate the unit
has arrived intact. In the event damage has been found or parts are
missing, please contact our toll free customer support number for fur-
ther instructions. Please do not return this unit to your dealer without
contacting customer support rst.
Introduction: The Quad Phase HP is a four channel, DMX intelligent
LED moonflower fixture. The fixture can operate in as a stand alone
fixture or in a Master/Slave configuration. The Quad Phase HP has two
operating modes; sound active and DMX Control. For best results use
fog or special effects smoke to enhance the beams projections.
Customer Support: ADJ Products, LLC provides a toll free cus-
tomer support line, to provide help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.adj.com for any comments or
suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@adj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! This may cause eye damage. Avoid looking directly into the
light source. Use sensible precaution.
