Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Quad Phase HP Specifications
Model: Quad Phase HP
Voltage*: 100V ~ 240V 50/60Hz
LED: 1 x 32 4-in-1 Watt LED
Power Draw: 64W
Fuse: 7A
Power Cord Daisy Chain: 5 Fixtures Max.
Dimensions: 12.5”(L) x 8”(W) x 11”(H)
312mm x 198mm x 279mm
Weight: 9 lbs. / 4 kgs.
Colors: RGBW
Beam Angle: 65 Degree
Duty Cycle: None
DMX Channels: 4
Sound Active: Yes
Working Position: Any Safe, Secure Position
Warranty: 3 Year (1095 days)
*Auto Sensing Voltage: This xture contains a automatic volt-
age switch, which will auto sense the voltage when it is plugged
into the power source.
ADJ Products, LLC
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-725-6100
Web: www.adj.com / E-mail: info@adj.com
A.D.J. Supply Europe B.V.
Junostraat 2
6468 EW Kerkrade
Netherlands
service@adj.eu / www.adj.com
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 19
