User Instructions
American DJ® - www.americandj.com - Matrix Beam LED Instruction Manual Page 2
Matrix Beam LED General Information
Unpacking: Thank you for purchasing the Matrix Beam LED by Amer-
ican DJ®. Every Matrix Beam LED has been thoroughly tested and has
been shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your xture for any
damage and be sure all equipment necessary to operate the unit has
arrived intact. In the event damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Please do not return this unit to your dealer without con-
tacting customer support rst.
Introduction: The Matrix Beam LED is designed as a blinder/cyc
effect or as a matrix chase effect for stages and mobile productons.
This fixture has built-in light chases with the option to create alpha-
betical and numerical characters. The fixture has four different operat-
ing modes; show mode, manual mode, sound-active, and DMX mode.
The Matrix Beam LED has 3 DMX Channel Modes; 1 Channel mode,
4 Channel mode, and 25 Channel mode. The fixture can be used as
a stand alone unit or connected in a master/slave configuration. For
best results use fog or special effects smoke to enhance the beams
projections.
Customer Support: American DJ® provides a toll free customer
support line, to provide help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Warning! This may cause severe eye damage. Avoid looking directly
into the light source at all times!
