ADJ Hypnotic RGB Руководство по эксплуатации онлайн
User Instructions
©American DJ® - www.americandj.com - Hypnotic RGB Instruction Manual Page 2
Unpacking: Thank you for purchasing the Hypnotic RGB by Ameri-
can DJ®. Every Hypnotic RGB has been thoroughly tested and has
been shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your xture for any
damage and be sure all equipment necessary to operate the unit has
arrived intact. In the event damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Please do not return this unit to your dealer without con-
tacting customer support rst.
Introduction: The Hypnotic RGB is an incredible 2 channel DMX
intelligent, red, green, and blue laser fixture. These are unique “web
type” laser effects that create incredible patterns. The Hypnotic RGB
can operate as a stand alone fixture or in a Master/Slave configura-
tion. The Hypnotic RGB can be a sound active fixture or it can also be
controlled via DMX. For best results use fog or special effects smoke
to enhance the beams projections.
Customer Support: American DJ® provides a toll free customer sup-
port line, to provide set up help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.americandj.com for any com-
ments or suggestions. For service related issue please contact Ameri-
can DJ®. Service Hours are Monday through Friday 8:00 a.m. to 4:30
p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ customer support.
PLEASE recycle the shipping carton whenever possible.
Hypnotic RGB General Introduction
6/11
