User Instructions
46HP LED Introduction
©American DJ® - www.Americandj.com - 46HP LED User Manual Page 2
10/08
Unpacking: Thank you for purchasing the 46HP LED by American
DJ®. Every 46HP LED has been thoroughly tested and has been shipped
in perfect operating condition. Carefully check the shipping carton for
damage that may have occurred during shipping. If the carton appears
to be damaged, carefully inspect your xture for any damage and be
sure all accessories necessary to operate the unit has arrived intact. In
the case damage has been found or parts are missing, please contact
our toll free customer support number for further instructions. Do not
return this unit to your dealer without rst contacting customer sup-
port.
Introduction: The American DJ® 46HP LED is part of a continuing
pursuit to create high quality intelligent lighting. The 46HP LED is a
DMX intelligent, high powered LED par can. This xture can be used
in a stand alone mode or connected in a Master/Slave conguration.
The unit can also be controlled via DMX controller. This wash has four
operating modes: Sound Active mode, Auto mode, RGB mode, and
DMX control mode.
Customer Support: American DJ provides a customer support line,
to provide set up help and to answer any question should you encoun-
ter problems during your set up or initial operation. You may also visit
us on the web at www.American DJ.com for any comments or sugges-
tions. Service Hours are Monday through Friday 9:00 a.m. to 5:00 p.m.
Pacic Standard Time.
Voice: (323) 582-3322
Fax: (323) 582-3108
E-mail: support@American DJ.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ.
PLEASE recycle the shipping carton when ever possible.
American DJ®
6122 S. Eastern Ave.
Los Angeles CA. 90040
www.americandj.com
