ADJ 46HP LED polish [4/10] Led display on off
![ADJ 46HP LED polish [4/10] Led display on off](/views2/1990721/page4/bg4.png)
©American DJ® - www.Americandj.com - 46HP LED User Manual Page 8
46HP LED Operating Instructions
46HP LED Operating Instructions
©American DJ® - www.Americandj.com - 46HP LED User Manual Page 7
LED Display On/Off:
To set the LED display to turn off after 10 seconds, press the MODE
button until 0001 is displayed, press the UP button to display 0002.
Now the display will disappear after 10s. Press any button to turn
the display on again. Be advised though that the display will turn off
automatically after 10 seconds.
To set the display press the MODE button until 0001 is displayed. The
display will now stay on at all times.
0001= LCD display on at all times.
0002= LCD display shuts off after 10 seconds.
Operating Modes:
You can use the 46HP LED in four ways:
• Sound-Active mode - The unit will react to sound, chasing through the
built in programs.
• Macro Mode - There are 32 color macros to choose from.
• Auto Mode - There are 6 built in programs to choose from.
• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller such as
as the American DJ® Show Designer™.
Master-Slave Operation:
This function will allows you to link units together to run in a Master-
Slave mode. In Master-Slave operation one unit will act as the controlling
unit and the others will react to the controlling units built-in programs.
Any unit can act as a Master or as a Slave however, only one unit can be
programmed to act as the “Master.”
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit.
Use standard XLR microphone cables to link your units together.
Remember that the Male XLR connector is the input and the Female
XLR connector is the ouput. The first unit in the chain (master) will
use the female XLR connector only. The last unit in the chain will use
the male XLR connector only.
2. Set the “Master” unit to your desired mode or operation.
3. For the “Slave” unit(s), set the display to DMX mode 3, or 3 Channel
mode. The display should read “3000” or any variables, i.e “3001”,
“3002 etc..
4. Connect the “Slave” unit or units and they will automatically start to
follow the “Master.”
Sound Active Mode:
In this mode the 46HP LED will react to sound, and chase through the
different colors.
1. Plug the fixture in and press the MODE button until “7-So” is dis-
played.
2. The fixture will now change via sound.
Macro Mode:
1. Plug the fixture in and press the MODE button until “8-XX” is dis-
played.
2. There are 32 macros to choose from. Select your desired macro by
pressing the UP and DOWN buttons.
Auto Mode:
1. Plug the fixture in and press the MODE button until “9-XX” is dis-
played.
2. There are 6 built in programs to choose from. Select your desired
program by pressing the UP and DOWN buttons. You can set your
program speed by following the instructions below.
Auto Mode Speed Adjustment:
1. To adjust the speed of your Auto mode program press the MODE
button until “A-XX” is displayed.
2. Press the UP or DOWN buttons to make the adjustmetns. “A-01” is
the slowest speed, “A-15” the fastest speed. When the display
reads “A-00” the Auto mode is running by sound activity. Set to your
desire.
RGB Mode:
1. Plug the fixture in and press the MODE button until:
2. When XXX is displayed you are in Red dimming mode. Press the
UP and DOWN buttons to adjust intensity.
3. When XXX is displayed you are in Green dimming mode. Press the
UP and DOWN buttons to adjust intensity.
3. When XXX is displayed you are in Blue dimming mode. Press the
UP and DOWN buttons to adjust intensity.
DMX Mode:
Operating through a DMX controller gives the user the freedom to create
