©American DJ® - www.Americandj.com - 46HP LED User Manual Page 13 ©American DJ® - www.Americandj.com - 46HP LED User Manual Page 14
Channel Value FunCtion
1 RED
1 - 255 0% - 100%
2 GREEN
1 - 255 0% - 100%
3 BLUE
1 - 255 0% - 100%
4 1 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
5 0 - 15 NOTHING
16 - 255 STROBING/SPEED CONTROL
SLOW - FAST
6 MODE
0 - 127 COLOR ADJUSTMENT
128 - 159 COLOR MIXING
160 - 191 3 COLOR CHANGE
192 - 223 7 COLOR CHANGE
224 - 255 SOUND ACTIVE
7 MASTER DIMMER
1 - 255 0% - 100%
46HP LED 7 Channel - DMX Values & Functions
Channel 1, 2, and 3 will not work, when Channel 4 is being
used.
When using Channel 6, Channel 5 will control the speed of the
color changing.
46HP LED Back/Silver Photometric
RED
0. 5
1
2
3
1
2
3
1. 5
3
5 -- -Dista n c e ( me t ers)
0
2
0. 3 1 2
0. 5 7 5
0. 9 7 0
1. 4 9 7 ---Di a m ter (m eters)
GREEN
0. 5
1
2
3
1
2
3
1. 5
3
5 -- - Distan c e ( me t e rs)
0
0. 3 1 2
0. 5 7 5
0. 9 7 0
1. 4 9 7 ---Di a m ter (m e ters)
7620 1271 338 123.9
BLUE
0. 5
1
2
3
1
2
3
1. 5
3
5 -- - Distan c e ( me t e rs)
0
0. 3 1 2
0. 5 7 5
0. 9 7 0
1. 4 9 7 ---Di a m ter (m eters)
436 85.7 22.6 9.7
WHITE
0. 5
1
2
3
1
2
3
1. 5
3
5 -- - Distan c e ( me t e rs)
0
0. 3 1 2
0. 5 7 5
0. 9 7 0
1. 4 9 7 ---Di a m ter (m eters)
10770
1760 476 180.2
46HP LED Photometrics
