46HP LED Operating Instructions
their own programs tailored to their own individual needs. This function
also allows you to use your fixtures as spot lights. The 46HP LED has
6 DMX modes: 1 Channel mode, 2 Channel mode, 3 Channel mode, 4
Channel mode, 6 Channel mode, and a 7 Channel mode. See pages 10-
12 for each modes’ DMX traits.
1. This function will allow you to control each individual fixture’s traits
with a standard DMX 512 controller.
2. To run your fixture in DMX mode, plug in the fixture via the XLR con-
nections to any standard DMX controller. Select your desired DMX
mode, and then press the UP or DOWN buttons to adjust the DMX
address.
3. To run the 1 Channel Mode, press the MODE button until “1000”
is displayed. This is the DMX addressing for the 1 Channel Mode.
4. To run the 2 Channel Mode, press the MODE button until “2000”
is displayed. This is the DMX addressing for the 2 Channel Mode.
5. To run the 3 Channel Mode, press the MODE button until “3000”
is displayed. This is the DMX addressing for the 3 Channel Mode.
6. To run the 4 Channel Mode, press the MODE button until “4000”
is displayed. This is the DMX addressing for the 4 Channel Mode.
7. To run the 6 Channel Mode, press the MODE button until “5000”
is displayed. This is the DMX addressing for the 6 Channel Mode.
8. To run the 7 Channel Mode, press the MODE button until “6000”
is displayed. This is the DMX addressing for the 7 Channel Mode.
9. Please see pages 10-13 for DMX values and traits.
46HP LED 1 Channel - DMX Values & Functions
Channel Value Function
1 COLOR MACROS
1 - 7 BASTARD AMBER
8 - 15 MEDIUM AMBER
16 - 23 PALE AMBER GOLD
24 - 31 GALLO GOLD
32 - 39 GOLDEN AMBER
40 - 47 LIGHT RED
48 - 55 MEDIUM RED
56 - 63 MEDIUM PINK
64 - 71 BROADWAY PINK
72 - 79 FOLLIES PINK
80 - 87 LIGHT LAVENDER
88 - 95 SPECIAL LAVENDER
96 - 103 LAVENDER
104 - 111 INDIGO
112 - 119 HEMSLEY BLUE
120 - 127 TIPTON BLUE
128 - 135 LIGHT STEEL BLUE
136 - 143 LIGHT SKY BLUE
144 - 151 SKY BLUE
152 - 159 BRILLIANT BLUE
160 - 167 LIGHT GREEN BLUE
168 - 175 BRIGHT BLUE
176 - 183 PRIMARY BLUE
184 - 191 CONGO BLUE
192 - 199 PALE YELLOW GREEN
200 - 207 MOSS GREEN
208 - 215 PRIMARY GREEN
216 - 223 DOUBLE CTB
224 - 231 FULL CTB
232 - 239 HALF CTB
240 - 247 DARK BLUE
248 - 255 WHITE
