User Instructions
©American DJ® - www.americandj.com - Galaxian Royale Instruction Manual Page 2
Unpacking: Thank you for purchasing the Galaxian Royale by Ameri-
can DJ®. Every Galaxian Royale has been thoroughly tested and has
been shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your xture for any
damage and be sure all equipment necessary to operate the unit has
arrived intact. In the event damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Please do not return this unit to your dealer without con-
tacting customer support rst.
Introduction: The Galaxian Royale is an incredible four channel DMX
intelligent, green and purple laser fixture. The purple laser is an great
laser effect, and combined with the green laser creates an incredible
3D effect. The Galaxian Royale can operate as a stand alone fixture, or
in a Master/Slave configuration. The Galaxian Royale can be a sound
active fixture or it can also be controlled via DMX. For best results use
fog or special effects smoke to enhance the beams projections.
Customer Support: American DJ® provides a toll free customer sup-
port line, to provide set up help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.americandj.com for any com-
ments or suggestions. For service related issue please contact Ameri-
can DJ®. Service Hours are Monday through Friday 9:00 a.m. to 4:30
p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ customer support.
PLEASE recycle the shipping carton whenever possible.
Galaxian Royale General Introduction
Rev. 10/10
