ADJ Comscan LED System Руководство по эксплуатации онлайн
12/09
User Instructions
American DJ® - www.americandj.com - Comscan LED Instruction Manual Page 2
Comscan LED General Information
Unpacking: Thank you for purchasing the Comscan LED by Ameri-
can DJ®. Every Comscan LED has been thoroughly tested and has
been shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your xture for any
damage and be sure all equipment necessary to operate the unit has
arrived intact. In the event damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Please do not return this unit to your dealer without con-
tacting customer support rst.
Introduction: The Comscan LED is a five channel DMX intelligent,
LED scanner. The Comscan LED can operate as a stand alone fixture
or in a Master/Slave configuration. The Comscan LED has three oper-
ating modes; sound active mode, show mode and DMX control. For
best results use fog or special effects smoke to enhance the beams
projections.
Customer Support: American DJ® provides a toll free customer
support line, to provide help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to
4:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Warning! This may cause severe eye damage. Avoid looking directly
into the light source at all times!
