American DJ® - www.americandj.com - Comscan LED Instruction Manual Page 13 American DJ® - www.americandj.com - Comscan LED Instruction Manual Page 14
Comscan LED Operation
on pages 5-7 as well as the set-up specifications that are includ-
ed with your DMX controller.
3. Use the controller’s faders to control the various DMX fixture traits.
4. This will allow you to create your own programs.
5. Follow the instructions on page 9 to set the DMX address.
6. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
7. For help operating in DMX mode consult the manual included
with your DMX controller.
Sound Active Mode: This mode allows either single unit or several
units linked together, to run to the beat of the music.
1. Tap the MENU button until “SOUN” is displayed, and press
ENTER.
2. Press ENTER then press and hold MENU for 3 seconds to corm.
3. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Show Mode: In this mode you can choose 1 of 12 show modes to
run.
1. Tap the MENU button until “SHND” is displayed, and press
ENTER.
2. Tap the UP or DOWN buttons until you nd your desired show,
and press ENTER then press and hold MENU for 3 seconds to
con rm. See page 9 for more info.
3. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Comscan LED UC3 Control
Blackout Blackout the unit
Function
1. Synchronous Strobe
2. Two light Strobe
3. Sound Strobe
Show Select
(show0-12)
Gobo Select
(8+open)
Mode
Sound/Strobe
(LED OFF)
Chase
(LED ON)
Gobo
(LED blinking)
Comscan LED DMX Values & Traits
Channel Value Function
1 0 - 255 PAN
2 0 - 255 TILT
3 STROBE
0 - 7 BLACKOUT
8 - 15 OPEN
16 - 131 STROBING SLOW - FAST
132 - 139 OPEN
140 - 181 SLOW OPEN - FAST CLOSE
182 - 189 OPEN
190 - 231 FAST OPEN - SLOW CLOSE
232 - 239 OPEN
240 - 247 RANDOM STROBE
248 - 255 OPEN
4 GOBO WHEEL
0 - 7 OPEN
8 - 14 GOBO 1
15 - 21 GOBO 2
22 - 28 GOBO 3
29 - 25 GOBO 4
36 - 42 GOBO 5
43 - 49 GOBO 6
50 - 56 GOBO 7
57 - 63 GOBO 8
64 - 71 OPEN SHAKE
72 - 78 GOBO 1 SHAKE
79 - 85 GOBO 2 SHAKE
86 - 92 GOBO 3 SHAKE
93 - 99 GOBO 4 SHAKE
100 - 106 GOBO 5 SHAKE
107 - 113 GOBO 6 SHAKE
114 - 120 GOBO 7 SHAKE
121 - 127 GOBO 8 SHAKE
128 - 255 GOBO WHEEL ROTATION SLOW - FAST
5 0 - 255 MASTER DIMMER 0% - 100%
