Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Comscan LED Specifications
Model: Comscan LED
Voltage: 100 ~ 240V 50Hz/60Hz “Auto Sensing”
LEDs: 1 X 10 Watt LED
Power Consumption: 30W
Dimensions: 13.5”(L) x 6.25”(W) x 8”(H)
344mm x 160mm x 200mm
Weight: 8 Lbs. / 3.6 kgs.
Beam Angle: 13 Degrees
Pan: 166 Degree (DMX);
104 Degree (Sound Active)
Tilt: 54 Degree (DMX);
40 Degree (Sound Active)
Gobos/Colors: 8 + Spot
Fuse: 2 Amp
Duty Cycle: None
DMX: 5 DMX Channels
Sound Active: Yes
Working Position: Any Safe, Secure Position
Warranty: 3 Year (1095 days)
American DJ® - www.americandj.com - Comscan LED Instruction Manual Page 19
Auto Sensing Voltage: This xture contains a electronic bal-
last, which will auto sense the voltage when it is plugged into the
power source.
