©American DJ® - www.americandj.com - Atmospheric RG LED Instruction Manual Page 2
Unpacking: Thank you for purchasing the Atmospheric RG LED
by American DJ®. Every Atmospheric RG LED has been thoroughly
tested and has been shipped in perfect operating condition. Carefully
check the shipping carton for damage that may have occurred during
shipping. If the carton appears to be damaged, carefully inspect your
xture for any damage and be sure all equipment necessary to oper-
ate the unit has arrived intact. In the event damage has been found
or parts are missing, please contact our toll free customer support
number for further instructions. Please do not return this unit to your
dealer without contacting customer support rst.
Introduction: The Atmospheric RG LED is an incredible 2 chan-
nel DMX intelligent, red & green laser, and dark blue LED fixture. The
unique “web type” laser combined with the LED creates a psychedelic
atmospheric effect. The Atmospheric RG LED can operate as a stand
alone fixture or in a Master/Slave configuration. The Atmospheric RG
LED has three operating modes; sound active mode, show mode, or it
can be controlled via DMX. For best results use fog or special effects
smoke to enhance the beams projections.
Customer Support: American DJ® provides a toll free customer sup-
port line, to provide set up help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.americandj.com for any com-
ments or suggestions. For service related issue please contact Ameri-
can DJ®. Service Hours are Monday through Friday 8:00 a.m. to 4:30
p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ customer support.
PLEASE recycle the shipping carton whenever possible.
Atmospheric RG LED General Introduction
Rev. 3/14
